Paper Packaging Testing

1. Product Introduction

The automatic thickness tester is an intelligent instrument for measuring the thickness of paper and paperboard. It can also be used to measure the thickness of articles in other industries.

2. Technical Parameters

1. Measuring range: (0~5) mm
2. Accuracy: 0.001 mm
3. Resolution: 0.001 mm
4. Indication error: ±0.0025 mm or ±0.5%
5. Indication variability: ±0.0025 mm or ±0.5%
6. Measuring parallelism: ≤0.002 mm
7. Contact area: (200±5) mm²
8. Contact pressure: (100±10) kPa
9. Descending speed: (0.5~10) mm/s, adjustable
10. Data storage: 20 sets
11. Data printing: Integrated modular thermal printer
12. Overall dimension (L×W×H): 320 mm×310 mm×380 mm
13. Weight: Approx. 27 kg
14. Power supply: AC220V ±10%, 2A, 50Hz
