Product Introduction
The water‑circulating sheet former is a paper‑making laboratory sheet‑forming equipment for preparing 200‑mm paper samples from pulp. It features fast sheet‑making speed, stable, intuitive and reliable performance, small footprint, easy disassembly, operation and movement. It adopts white‑water circulation, electric water feeding, dual homogenization modes of pneumatic bubble agitation and manual agitation, quick water draining, and external vacuum suction access. The cabinet is made of stainless steel. Its technical indexes comply with QB/T 3703‑1999 (Preparation of handsheets for pulp laboratory‑Conventional handsheet former method). Equipped with special sealing and clamping device, it avoids common defects such as rough edges and pulp leakage during sheet‑making process.
Technical Parameters
- Sheet‑making cylinder diameter: 200 mm
- Sheet‑making cylinder volume: 10 L, water draining time: 3 s
- Equipment power: 370 W
- Overall dimension: 940 mm×600 mm×1400 mm
