Compliance Standards: GB 2611, GB/T 228, GB/T 7314, GB/T 232, JJG 139, etc. Product Application: It is applied for mechanical property tests including tension, compression and bending for various meta…
Product Application: It is applied for mechanical property tests including tension, compression and bending for various metallic materials, non‑metallic materials, product parts, components, structural parts and standard fasteners. When this series of testing machine is equipped with optional environmental accessories, it can also perform tensile, compression and bending tests under corresponding environmental conditions, such as high‑temperature tensile test, low‑temperature tensile test and compression test.
Item
Specification
Model
KT‑B700 (Touch Screen Control)
Test Force
20000N (Optional range: 0.1N‑20000N)
Tester Grade
Class 1
Indication Error
≤±0.5%
Load Measuring Range
0.4%～100% FS
Tester Resolution
1/250000 counts
Effective Tensile Stroke
0‑800 mm
Speed Adjustment Range
50～300 mm/min
Motor Power
0.37 KW
Power Supply
220V, 50Hz
Net Weight
200 Kg
Overall Dimension of Main Unit
1100×700×2000 mm
Additional Features
Users may set appropriate fracture stop‑time for different materials
