Product Introduction
This equipment is mainly used for enclosure protection rating tests (IP waterproof rating tests) of outdoor lighting, outdoor lamps, swimming pool lamps, automotive lamps, household electrical appliances, electrical and electronic products, communication products, signal devices and other products. It is a special testing equipment for waterproof protection grade inspection, an ideal test device for professional testing institutions, and applicable to other equivalent water test methods.
Item
Parameter
Equipment Name
IPX8 Water Immersion Test Device
Model
KT-X8-5
Internal Height of Test Device
1700 mm
Outer Diameter of Test Device
Φ330 mm
Simulated Water Depth Range
1–500 m
Pressure Adjustment Range
0.1–5.0 MPa
Material of Test Device
Main structure fully made of stainless steel
Pressurization Method
Pneumatic booster cylinder, pressure ratio: 10:1
Accuracy of Pressure Sensor
±0.5%FS
Pressure Control Accuracy
±0.1 MPa
Control Mode
Digital display controller
Ambient Temperature
Room temperature
Control Cabinet Dimension
Approx. 1000mm700mm1100mm
High-pressure Chamber
Inner diameter 330mm, height 1700mm
Power Supply
AC 220V
Air Source Requirement
Customer to prepare air compressor. Recommended output air pressure: 0.8MPa–1.2MPa
Remarks
Customization available according to customer requirements
