Product Introduction
It is specially designed for drying heat-sensitive, easily decomposable and oxidizable substances. Inert gas can be filled into the chamber to realize rapid drying even for articles with complex compositions.
Product Features
Digital LED display; microcomputer temperature controller ensures accurate and reliable temperature control with timing function.
Rectangular 304 stainless steel working chamber maximizes effective volume, durable and easy to clean.
Tempered double-layer safety glass door allows direct observation of samples inside the chamber.
Tightness of the chamber door is adjustable; integrally molded silicone rubber sealing ring guarantees high vacuum degree inside the chamber.
Storage, heating, testing and drying processes are carried out under oxygen-free or inert gas environment to avoid oxidation of samples.
Item
Parameter
Model
KT-E370
Power Supply
AC220V, 50Hz
Temperature Control Range
Internal heating: RT+10～200℃
Temperature Fluctuation
±1.0℃
Ultimate Vacuum Degree
100Pa
Rated Power (W)
2200W
Inner Chamber Size (mm)
560×600×650
Overall Dimension (mm)
720×805×1580
Shelves (Pcs)
3 pieces
Inner Chamber Material
Stainless steel (1Cr18Ni9Ti)
Timing Range
1–9999 min/h
Technical parameters in the table are measured under the conditions: ambient temperature 25℃, relative humidity ≤85%, vacuum degree ≥0.1MPa, using a thermometer with accuracy of ±0.1℃. The probe of the thermometer shall be in good contact with the surface of the shelf inside the chamber.
