Paper Packaging Testing

Product Introduction

The tearing strength tester is used to measure the tear resistance of various types of paper and paperboard. It is designed based on the Elmendorf tearing principle. It is also applicable for testing tear‑resistant performance of plastic films, composite films, thin sheets, textiles and non‑woven fabrics.

Technical Parameters

1. Measuring range: 10 mN ~ 11000 mN
2. Resolution: 0.1 mN
3. Accuracy: ±1.0%
4. Tear pendulum arm length: 104 mm ±1 mm
5. Initial tearing angle: 27.5°±0.5°
6. Tearing distance: 43±0.5 mm
7. Specimen clamp size: 25 mm ×15 mm
8. Distance between clamps: 2.8 mm ±0.3 mm
9. Specimen pre‑cut length: 20 mm ±0.5 mm
10. Working environment: Temperature (0~35) ℃, humidity＜85%
11. Power supply: AC220V, 50Hz
